ProLiant ML530 Servers Maintenance and Service Guide

Removal and Replacement Procedures 2-39
To remove an SDRAM DIMM:
1. Perform the preparation procedures. See “Powering Down the Server” earlier in this
chapter.
2. Remove the access panel. See “Access Panel” earlier in this chapter.
3. Press both SDRAM DIMM socket latches outward.
4. Pull out the SDRAM DIMM .
1
2
1
Figure 2-32. Removing an SDRAM DIMM
Reverse steps 1 through 4 to replace an SDRAM DIMM.
IMPORTANT: A memory module can be installed one way only. Be sure to match the key sockets on the
module with the tab on the memory socket. Push the module down into the socket, ensuring that the
module is fully inserted and properly seated.
