3-14 Compaq ProLiant ML530 Servers Maintenance and Service Guide
Table 3-2
POST Error Messages
continued
Error Code Audible Beeps Probable Source of Problem Recommended Action
1729-Slot 1 Drive
Array – Disk
Consistency
Initialization in
Progress – RAID 4/5
performance may be
lower until
auto-reliability
monitoring has
completed
auto-background
parity consistency
initialization.
None Initial RAID configuration in
progress.
Normal message following
initialization, no action required.
1730-Fixed Disk 0
does not support
DMA Mode.
None Hard drive error Run the System Configuration
Utility and correct.
1731-Fixed Disk 1
does not support
DMA Mode.
None Hard drive error Run the System Configuration
Utility and correct.
1740-Fixed Disk 0
failed Set Block
Mode command.
None Hard drive error Run the System Configuration
Utility and correct.
1741-Fixed Disk 1
failed Set Block
Mode command.
None Hard drive error Run the System Configuration
Utility and correct.
1750-Fixed Disk 0
failed Identify
command.
None Hard drive error Run the System Configuration
Utility and correct.
1751-Fixed Disk 1
failed Identify
command.
None Hard drive error Run the System Configuration
Utility and correct.
1760-Fixed Disk 0
does not support
Block Mode.
None Hard drive error Run the System Configuration
Utility and correct.
1761-Fixed Disk 1
does not support
Block Mode.
None Hard drive error Run the System Configuration
Utility and correct.
continued
