3-28 Compaq ProLiant ML530 Servers Maintenance and Service Guide
500–599, Video Display Unit Test Error Codes
The 500 series of diagnostic error codes identifies failures with video or system board functions.
Table 3-7
Video Display Unit Test Error Codes
Error Code Description Recommended Action
501-xx Video controller test failed.
502-xx Video memory test failed.
503-xx Video attribute test failed.
504-xx Video character set test failed.
505-xx Video 80 × 25-mode 9 × 14
character cell test failed.
506-xx Video 80 × 25-mode 8 × 8
character cell test failed.
507-xx Video 40 × 25-mode test failed.
508-xx Video 320 × 200-mode color set 0
test failed.
509-xx Video 320 × 200-mode color set 1
test failed.
510-xx Video 640 × 200-mode test failed.
511-xx Video screen memory page test
failed.
512-xx Video gray scale test failed.
514-xx Video white screen test failed.
516-xx Video noise pattern test failed.
1. Replace the monitor and retest.
2. Replace the Advanced VGA board and retest.
3. Replace the system board and retest.
