Diagnostics and Troubleshooting 3-31
1200–1299, Modem Communications Test Error Codes
The 1200 series of diagnostic error codes identifies failures with the modem.
Table 3-11
Modem Communications Test Error Codes
Error Code Description Recommended Action
1201-xx Modem internal loopback test
failed.
1202-xx Modem time-out test failed.
1203-xx Modem external termination test
failed.
1204-xx Modem auto originate test failed.
1206-xx Dial multi-frequency tone test
failed.
1210-xx Modem direct connect test failed.
1. Refer to the modem documentation for correct
setup procedures and retest.
2. Check the modem line and retest.
3. Replace the modem and retest.
