Diagnostics and Troubleshooting 3-35
6000–6099, Compaq NIC Boards Test Error Codes
The 6000 series of diagnostic error codes identifies failures with 32-bit DualSpeed
NetFlex-2/Token Ring Controllers.
Table 3-15
Compaq Network Interface Controller Boards Test Error Codes
Error Code Description Recommended Action
6000-xx Network card ID failed.
6001-xx Network card setup failed.
6002-xx Network card transmit failed.
6014-xx Network card configuration failed.
6016-xx Network card reset failed.
6028-xx Network card internal failed.
6029-xx Network card external failed.
6089-xx Network card open failed.
6090-xx Network card initialization failed.
6091-xx Network card internal loopback failed.
6092-xx Network card external loopback failed.
1. Check the controller installation in the PCI
slot.
2. Check the interrupt type and number
setting.
3. Check the media connection at the
controller and Multistation Access Unit
(MAU).
4. Check the media speed (4/16) and type of
Unshielded Twisted Pair/Shielded Twisted
Pair (UTP/STP) settings.
5. Check the MAU, cabling, or other network
components.
6. Replace the controller.
