HP ProLiant SL390s G7 2U Half-width Server Installation Sheet Part Number 614093-004 March 2013 (Fourth Edition)
Item Description 5 NIC 1/iLO 3 connector 6 NIC 2 connector 7 USB connectors 8 UID LED/SW 9 HDD 1 10 HDD 2 11 Front PCIe bracket (LP slot) 12 Power LED/SW 13 HDD 3 14 HDD 4 15 iLO 3 network port Rear Panel Components Figure 2 Rear panel components of the s6500 chassis with four SL390s 2U servers Identifying Chassis Components Front Panel Components Figure 1 Front panel components of the s6500 chassis with four SL390s 2U servers Item Description 1 VGA port 2 Serial port 3 SFP
Server Configuration Resources In addition to this Installation Sheet, other resources are available for more information regarding the configuration and maintenance of your server: • • • For safety information and detailed procedures relating to installation of options, refer to any installation instructions that came with the option, as well as the HP ProLiant SL390s G7 2U Half-width Server Maintenance and Service Guide.
CAUTION: Drives can be damaged by static electricity. Before handling drives, touch an unpainted metal surface to discharge static electricity. To install a non-hot-plug SFF hard disk drive or SSD (quick release drive carrier): Install the hard drive assembly on the tray and make sure the notch on the carrier locked on the tray. • Speed is 800 MHz, 1067 MHz, 1333 MHz depending on the DIMM population. • DIMM voltage is 1.5V and LV 1.35V.
Installing a Processor Figure 10 Reinserting a processor The HP ProLiant SL390s G7 2U Half-width Server supports Intel Nehalem and Westmere Processors High Wattage 95W,80W (Dual CPUs 64-bit), and Nehalem Processors Low Wattage 60W and Westmere Processor Low Wattage 40W(Dual CPUs 64-bit). NOTE: If one processor is being installed, it should be installed in the socket furthest from the IOH/chipset. To install a processor: CAUTION: Use the processor installation tool to insert the processor into the socket.
Figure 12 Removing the processor installation tool 5. Figure 14 Installing the heatsink IMPORTANT: If the heatsink has been removed for any reason, it is critical that you apply more thermal interface material to the integrated heat spreader on the processor to ensure proper thermal bonding between the processor and the heatsink. Clean the contact surface of both the processor and heatsink with an alcohol pad, then re-apply an HP-approved thermal interface material before reinstalling the processor.
Figure 16 Connecting the GPU cables 3. Reinstall the HDD module and fasten the screws. Figure 19 Reinstalling the HDD module To install a dual GPU kit: 1. Install the GPUs on the 2 GPU shelf. NOTE: For detailed information, refer to the HP Single GPU Riser Kit Installation Instructions, HP SL390s 2 GPU Riser Option Kit Installation Instructions. Figure 17 Installing the GPUs on the 2 GPU shelf.
Figure 21 Installing the BBWC bracket Additional Documentation You can access additional information and documentation from the HP external website. Documentation Feedback HP is committed to providing documentation that meets your needs. To help us improve the documentation, send any errors, suggestions, or comments to Documentation Feedback (mailto:docsfeedback@hp.com). Include the document title and part number, version number, or the URL when submitting your feedback. 3.
