HP ProLiant SL390s G7 2U Half-width Server Installation Sheet

Identifying Chassis Components
Front Panel Components
Figure 1 Front panel components of the s6500 chassis with four
SL390s 2U servers
Item Description
1 VGA port
2
Serial port
3
SFP PLUS connector
4
QSFP
Item Description
5
NIC 1/iLO 3 connector
6
NIC 2 connector
7
USB connectors
8
UID LED/SW
9
HDD 1
10
HDD 2
11
Front PCIe bracket (LP slot)
12
Power LED/SW
13
HDD 3
14
HDD 4
15
iLO 3 network port
Rear Panel Components
Figure 2 Rear panel components of the s6500 chassis with four SL390s
2U servers
Item Description
1 Power supply 1
2 Power supply 2
3 Power supply 3
4 Power supply 4
5 UID LED
6 APM connector
7 Fan 1
8 Fan 2
9 Fan 3
10 Fan 4
11 Fan 5
12 Fan 6
13 Fan 7
14 Fan 8
