Monitoring and managing the Director
108 Director Element Manager User Guide
■ FPM—G_Port, small form factor pluggable (SFP) optics, fibre port
module, 1 Gigabit
■ UPM—G_Port, small form factor pluggable (SFP) optics, universal
port module, 2 Gigabit
■ GSFM—G_Port, short wave, small form factor, multimode, 1 Gigabit
■ GLSR—G_Port, short wave, single mode, MT-RJ connector,
1 Gigabit
■ GXXR—G_Port, mixed mode, MT-RJ connector, 1 Gigabit
■ GXXL—G_Port, mixed mode, LC connector, 1 Gigabit
— Cooling FAN—Fan module.
— PWR—Power supply module.
■ Position—A number representing the FRU chassis position. The chassis (slot)
position for a nonredundant FRU is 0. The chassis positions for redundant
FRUs are 0 and 1. For the Director 2/64 chassis, port positions are 0–63. For
the Director 2/140 model, port positions are 0–127 and 132–143. Note that for
the Director 2/140, ports 128–131 are internal ports and are not available for
external connections.
■ Status—The FRU status (Active or Backup).
■ Part Number—The FRU part number.
■ Serial Number—The FRU serial number.
To display the FRU Properties dialog box for an FRU:
■ Click the FRU’s row and choose Product > FRU > FRU Properties.
Or
■ Double-click an FRU.
