Monitoring and managing the Director
110 Director Element Manager User Guide
Not
Operational
Off Off Yellow
Triangle
The director port is receiving the Fibre
Channel not operational sequence (NOS),
indicating that the attached device is not
operational.
Online On Off None The attached device has successfully
connected to the director and is ready to
communicate or is in the process of
communicating with other attached devices.
As long as the port remains online, the
green port LED remains illuminated. Note
that on the actual port in the unit, the green
LED blinks when there is active Fibre
Channel traffic through the port.
Offline Off Off None The director port was configured as
blocked
and is transmitting the Fibre Channel OLS to
the attached device.
Off Off Yellow
Triangle
The director port was configured as
unblocked
and is receiving the Fibre
Channel OLS, indicating that the attached
device is offline.
Port Failure Off On Red and
Yellow
Blinking
Diamond
The director port has failed and requires
service. The amber LED for the port remains
illuminated.
Segmented
E_Port
On Off Yellow
Triangle
The E_Port is segmented preventing the two
fabrics from joining (this only occurs when
two directors are connected to each other).
Display the Port Properties dialog box to
view the segmentation reason.
Table 4: Port states and indicators (Continued)
Port Indicators
Port State Green Amber
Alert
Indicator
1
Description
