Configuring the Director
117Director Element Manager User Guide
4. Enter a description of the director in the Description field (255 characters
maximum).
5. Enter the location of the director in the Location field (255 characters
maximum).
6. Enter appropriate information about a contact person, such as a phone
number, title, or e-mail address, in the Contact field (255 characters
maximum).
7. Click Activate to save the data and close the dialog box.
8. If you are finished configuring the director, back up the configuration data.
For more information, see “Backup and Restore Configuration” on page 186.
Configuring Management Style
To configure management style for the director, use the following steps:
1. Click Product > Management Style in the Element Manager window.
Note: To change this value, you must first set the director offline.
Note: If you change the management style to FICON, all ISL/E-Ports are disabled.
2. Click either the Open Systems or FICON option buttons:
■ Use Open Systems management style for all (non-FICON) Fibre Channel
environments.
■ If the FICON Management Server feature is enabled, the default
management style will be FICON. The management style cannot be
changed to Open Systems with the FICON Management Server feature
enabled. Typically, FICON management style is used when attaching an
IBM FICON Parallel Enterprise or IBM zSeries server to the director and
implementing inband director management through a Fibre Connection
(FICON) channel.
