11Director Element Manager User Guide
About this
Guide
About this Guide
About this Guide
This reference guide provides information to use when planning to acquire and
install one or more of the following Hewlett-Packard (HP) StorageWorks
products:
■ Director 2/64
■ Director 2/140
■ High Availability Fabric Manager (HAFM) application
The Director 2/64 is a 64-port director, while the Director 2/140 is a 140-port
director. Functions and options available through the Element Managers for these
products are nearly identical. When there are differences, this guide will contain
notes such as Director 2/64 only or Director 2/140 only.
“About this Guide” topics include:
■ Overview, page 12
■ Conventions, page 13
■ Rack Stability, page 15
■ Getting Help, page 16
