Configuring the Director
141Director Element Manager User Guide
5. Click in the Speed column for the port and click 1Gig, 2Gig, or Negotiate to
set the data speed for the port. When you click Negotiate, it allows the port
and attached device to negotiate the data rate.
Note: Note that your director model and firmware may not allow 2 Gb/s data
speeds.
6. Click the Bound WWN field and enter the WWN or nickname of the specific
device to be connected to the port.
7. Use the scroll bar on the right side of the Configure Ports dialog box table to
display additional ports that you want to configure.
8. Click Activate to activate the changes and close the dialog box.
9. If you are finished configuring the switch, back up the configuration data. For
more information, see “Backing Up and Restoring Configuration Data” on
page 164.
