Configuring the Director
146 Director Element Manager User Guide
■ Click Copy to copy a stored configuration. When the Copy Address
Configuration dialog box displays, provide a name and description for the
configuration.
Names must be between 1 and 8 characters in length. Valid characters are
uppercase A–Z, 0–9, hyphen (-), and underscore (_). The name may not
be CON, AUX, COMn (where n=1-9), LPTn (where n=1-9), NUL, or
PRN. Descriptions must be between 0 and 24 characters in length. Up to
24 alphanumeric characters are allowed, including spaces, hyphens, and
underscores. Click OK and the configuration is added to the library.
■ Click Activate to activate a stored configuration and send it to the switch
for immediate use. A warning displays before the action occurs.
Note: If Active=Saved is enabled through the Configure FICON Management
Server dialog box, this overwrites the current IPL address configuration.
3. Click Close to close the dialog box when you are finished managing the
library.
