Configuring the Director
161Director Element Manager User Guide
Deleting Alerts
Use the following steps to delete existing threshold alerts.
1. At the Hardware View page, click Configure > Threshold Alerts. The
Configure Threshold Alerts dialog box displays.
2. Choose the alert that you want to delete by selecting the alert information in
the table and clicking Delete. A message displays asking you to confirm the
deletion.
3. Click Yes. The alert is removed from the dialog box.
Configuring Open Trunking
This option is only available if the optional Open Trunking feature is installed.
Choosing this option opens the Configure Open Trunking dialog box. For details
on enabling Open Trunking and configuring such parameters as congestion
thresholds for ports, event notification options, and low BB_Credit threshold, see
“Open Trunking” on page 208.
