Using Maintenance Features
181Director Element Manager User Guide
7. Follow the on-screen instructions and click Next to continue through to the
next screen.
8. If you are finished configuring the director, back up the configuration data.
For more information, see “Backup and Restore Configuration” on page 186.
Notes:
■ Make sure that the system administrator varies devices offline that are
attached to the ports whose addresses you are going to swap.
■ Ports that you are going to swap are blocked during this procedure, as
swapping ports is disruptive to port operation.
Collect Maintenance Data
The Data Collection option enables you to collect maintenance data that can help
support personnel diagnose system problems. Save the maintenance data as a zip
file on a backup disk (or other medium with the appropriate capacity), and
forward it to technical support personnel.
Note: If the Full Volatility feature is enabled through the director’s maintenance port, a
memory dump file is not included with the data collection.
To use this option, follow the detailed steps in the HP StorageWorks Director 2/64
Service Manual for the Director 2/64 and the HP StorageWorks Director 2/140
Service Manual for the Director 2/140.
