Using Maintenance Features
184 Director Element Manager User Guide
Manage Firmware Versions
Firmware refers to the internal operating code for the director. You can maintain
up to eight firmware versions on the HAFM appliance for downloading to a
director. To use the Firmware Library option to manage firmware versions,
follow the steps in the HP StorageWorks Director 2/64 Service Manual for the
Director 2/64 and the HP StorageWorks Director 2/140 Service Manual for the
Director 2/140.
Enable E-Mail Notification
E-mail addresses and the simple mail transfer protocol (SMTP) server address for
e-mail notification of director events must be configured through the HAFM
application. Refer to the HP StorageWorks HA-Fabric Manager User Guide for
instructions on configuring e-mail.
Note: E-mail recipients are configured in the HAFM application through the Configure
E-Mail dialog box. A valid SMTP address is configured in this dialog box.
Use the Enable E-Mail Notification function on the Element Manager to enable
e-mail notification for events that occur on a selected director. The default state is
disabled.
To enable e-mail notification, use the following steps:
1. Choose Maintenance > Enable E-Mail Notification from the menu bar.
2. To enable e-mail notification, choose the option to add a check mark to the
check box.
3. To disable e-mail notification, choose the option to remove the check mark
from the check box.
