Using Maintenance Features
188 Director Element Manager User Guide
Reset Configuration
This feature is used to reset all configuration data for the director to factory
default values. You must have maintenance authorization rights to access this
feature.
The Internet protocol (IP) address will reset to the factory default value during this
procedure. You may not recover the Ethernet connection between the director and
HAFM appliance if you have changed the director’s IP addressing from that
default value. In this case you must reenter LAN addressing, such as IP and
gateway addresses, through a terminal attached to the maintenance port.
Before using the reset configuration option, record the director’s current IP
address, which displays below the icon in the HAFM application’s Product View
when the view’s Display Options are set to Network Address. You can also find
the current IP address through the Embedded Web Server interface.
After resetting the configuration, reset LAN addressing to the desired values
through the maintenance port or the Embedded Web Server interface.
If you have enabled the Full Volatility feature through the director’s maintenance
port, this feature will disable when the configuration is reset.
Note: Use of the maintenance port is not covered in this manual. For procedures, refer
to the
HP StorageWorks Director 2/64 Service Manual
for the Director 2/64 and the
HP StorageWorks Director 2/140 Service Manual
for the Director 2/140.
Use the following steps to reset the configuration parameters on the director to the
default values.
1. Choose Reset Configuration from the Maintenance menu. The following
warning displays:
WARNING: This operation will reset all director configuration data and
nonvolatile settings to factory default values. The director must be offline to
continue.
2. Set the director offline. For instructions, see ““Set Online State” on page 183.
