Using Maintenance Features
189Director Element Manager User Guide
3. To continue the reset operation, click Reset on the Reset Configuration dialog
box. If you want to cancel the operation, click Cancel.
Note: If you have enabled features that add additional port function since the director
was shipped from the factory, these features will be disabled (factory default) when the
configuration is reset. Only those ports that were enabled at the factory will function.
You will have to enable the additional port function features again through the
Configure Feature Key dialog box.
Factory-default values may vary, depending on the firmware release installed in
your director. For a list of values, refer to the HP StorageWorks Director 2/64
Service Manual for the Director 2/64 and the HP StorageWorks Director 2/140
Service Manual for the Director 2/140.
Table 7: Data default values
Configuration Description Default
Identification Director Name NULL string
Director Description “Fibre Channel Director”
Director Contact “End User Contact (please
configure)”
Director Location “End User Contact (please
configure)”
Ports Port Names NULL strings
Port Blocked States Unblocked
Extended Distance
(10–100 km)
Disabled
LIN Alerts Disabled
Port Address Port number plus 4
