Using Maintenance Features
190 Director Element Manager User Guide
Director
Addressing
IP Address 10, mac[3], mac[4], mac[5]
converted to word32
MAC addresses are set in
hexadecimal; IP addresses in
decimal. A MAC address of 08
00 88 20 00 57 will be reset to
an IP address of 10.32.0.87.
Subnet Mask 255.0.0.0
Gateway Address 0.0.0.0
MAC Address PROM value
Operating
Parameters
Preferred Domain ID 1
Buffer-to-Buffer Credit 16
R_A_TOV 10 seconds (100 tenths)
E_D_TOV 2 seconds (20 tenths)
Director Priority 254
Insistent Disabled
Rerouting Delay Enabled
Domain RSCNs Disabled
Suppress Zoning
RSCNs
Disabled
SNMP SNMP Communities “public”—5 NULL strings
SNMP Write
Authorizations
Read only per community
Trap Recipient IP
Addressees
0 for each
UDP Port 162
SNMP Authorization
Trap State
5
Table 7: Data default values (Continued)
Configuration Description Default
