Optional Features
196 Director Element Manager User Guide
To configure FICON management server, use the following steps:
1. Choose Configure > Management Server from the Element Manager menu
bar. The Configure FICON Management Server dialog box displays.
2. Click the Enable FICON check box to enable the management server. (To
disable the management server, click the check box again to remove the check
mark.)
3. Choose the Parameters option to open the Configure FICON Management
Server Parameters dialog box, as shown in Figure 65.
Figure 65: Configure FICON Management Server Parameters dialog box
4. Click the Switch Clock Alert Mode check box to enable or disable switch
clock alert mode. When a check mark displays, the alert mode is enabled.
5. Click the Host Control Prohibited check box to allow or prohibit host
control. When a check mark displays, host control is prohibited.
Table 8: Available code pages
Code Page
Name
Code Page
Hexadecimal
CPGID
United
States/Canada
00037 0025
Germany/
Austria
00273 0111
Brazil 00275 0113
Italy 00280 0118
Japan 00281 0119
Spain/Latin
America
00284 011C
United Kingdom 00285 011D
France 00297 0129
International #5 00500 01F4
