Information and Error Messages
214 Error Messages
HAFM Application Messages
This section lists HAFM application information and error messages in
alphabetical order.
Table 9: HAFM Messages
Message Description Action
A zone must have at
least one zone
member.
When creating a new
zone, one or more
zone members must be
added.
Add one or more zone
members to the new zone using
the Modify Zone dialog box.
A zone set must have
at least one zone.
When creating a new
zone set, one or more
zones must be added.
Add one or more zones to the
new zone set using the Modify
Zone dialog box.
All alias, zone, and
zone set names must
be unique.
When creating a new
alias, zone, or zone
set, the name must be
unique.
At the New Zone dialog box,
choose a unique name for the
new alias, zone, or zone set.
All zone members are
logged.
Attempt was made to
display all zone
members not logged in
using the Zone Set tab,
but all members are
currently logged in.
Informational message.
An HAFM application
session is already
active from this
workstation.
Only one instance of
the
HAFM
application
is allowed to be open
per remote
workstation.
Close all but one of the
HAFM
application sessions.
Are you sure you want
to delete this network
address?
The currently-selected
network address will
be deleted.
Click Yes to delete or No to
cancel.
Are you sure you want
to delete this
nickname?
The selected nickname
will be deleted from
the list of nickname
definitions.
Click Yes to delete the
nickname or No to cancel the
operation.
Are you sure you want
to delete this product?
The selected product
will be deleted from
the list of product
definitions.
Click Yes to delete the product
or No to cancel the operation.
Are you sure you want
to delete this user?
The selected user will
be deleted from the list
of user definitions.
Click Yes to delete the user or
No to cancel the operation.
