Information and Error Messages
215Director Element Manager User Guide
Are you sure you want
to delete this zone?
The selected zone will
be deleted from the
zone library.
Click Yes to delete the zone or
No to cancel the operation.
Are you sure you want
to delete this zone set?
The selected zone set
will be deleted from
the zone library.
Click Yes to delete the zone set
or No to cancel the operation.
Are you sure you want
to overwrite this zone
set?
The selected zone set
will be overwritten in
the zoning library.
Click Yes to overwrite or No to
cancel.
Are you sure you want
to remove all members
from this zone?
All members will be
deleted from the
selected zone.
Click Yes to delete the members
or No to cancel the operation.
Cannot add a switch
to a zone.
The device that you
are attempting to add
to the zone is a switch,
which cannot be
added to a zone.
Specify the port number or
corresponding World Wide
Name for the device you want
to add to the zone.
Cannot connect to
management server.
The
HAFM
application
at a remote
workstation could not
connect to the HAFM
appliance.
Verify the HAFM appliance
internet protocol (IP) address is
valid.
Cannot delete product. The selected product
cannot be deleted.
Verify the HAFM
appliance-to-product link is up.
If the link is up:
■ The HAFM appliance may
be busy.
■ Another Element Manager
instance may be open.
■ You may not have
permission to delete the
product.
Cannot disable Fabric
Binding while
Enterprise Fabric
Mode is active.
You attempted to
disable Fabric Binding
through the Fabric
Binding dialog box,
but Enterprise Fabric
Mode was enabled.
Disable Enterprise Fabric Mode
through the Enterprise Fabric
Mode dialog box in the
HAFM
application before disabling
Fabric Binding.
Table 9: HAFM Messages (Continued)
Message Description Action
