Information and Error Messages
216 Error Messages
Cannot display route.
All switches in route
must be managed by
the same server.
You cannot show the
route between devices
that are attached to
switches or directors
managed by a
different HAFM
appliance.
Make sure devices named in
Show Routes dialog box are
attached to products managed
by this HAFM appliance.
Cannot display route.
All switches in route
must support routing.
You cannot show the
route through a fabric
that has switches or
directors which do not
support routing.
The route must contain only
Edge Switch 2/16s, Edge
Switch 2/32s, Director 2/64s,
or Director 2/140s.
Cannot display route.
Device is not a
member of a zone in
the active zone set.
You cannot show the
route for a device that
is not a member of a
zone in the active zone
set. The source node
that you have selected
is not part of a zone in
the active zone set.
Enable the default zone or
activate the zone for the device
before attempting to show the
route.
Cannot display route
on one switch fabric.
You cannot show
routes between end
devices in a fabric
when configuring
Show Routes
(Configure menu).
Error displays when attempting
to show routes on a fabric with
only one switch. Configure
Show Routes on a multiswitch
fabric.
Cannot display route.
error 9.
An internal error has
occurred while trying
to view routes.
Contact the next level of
support to report the problem.
Cannot display route.
No active zone
enabled.
You cannot show the
route through a fabric
with no active zone.
Enable the default zone or
activate a zone set before
attempting to show the route.
Cannot have spaces in
field.
Spaces are not
allowed as part of the
entry for this field.
Delete spaces from the field
entry.
Cannot modify a zone
set with an invalid
name. Rename zone
set and try again.
A zone set must have
a valid name to be
modified.
Assign a valid name to the
zone set, then modify the name
through the Modify Zone Set
dialog box.
Table 9: HAFM Messages (Continued)
Message Description Action
