Information and Error Messages
217Director Element Manager User Guide
Cannot modify a zone
with an invalid name.
Rename zone and try
again.
A zone must have a
valid name to be
modified.
Assign a valid name to the
zone, then modify the name
through the Modify Zone Set
dialog box.
Cannot modify
product.
The selected product
cannot be modified.
Verify the HAFM
appliance-to-product link is up.
If the link is up:
■ The HAFM appliance may
be busy.
■ Another Element Manager
instance may be open.
■ You may not have
permission to modify the
product.
Cannot perform
operation. Fabric is
unknown.
This message displays
if no switches in the
fabric are connected
to the HAFM
appliance.
Ensure at least one
fabric-attached switch or
director has an Ethernet
connection to the HAFM
appliance and retry the
operation.
Cannot perform
operation. The list of
attached nodes is
unavailable.
This message displays
when attached nodes
are unavailable and
you attempt to modify
a zone or create a
new zone.
Verify an attached node is
available and retry the
operation.
Cannot retrieve current
SNMP configuration.
The current SNMP
configuration could
not be retrieved.
Try again. If the problem
persists, contact the next level
of support.
Cannot save current
SNMP configuration.
The current SNMP
configuration could
not be saved.
Try again. If the problem
persists, contact the next level
of support.
Cannot set write
authorization without
defining a community
name.
An SNMP community
name has not been
configured.
Enter a valid community name
in the Configure SNMP dialog
box.
Table 9: HAFM Messages (Continued)
Message Description Action
