Information and Error Messages
218 Error Messages
Cannot show zoning
library. No fabric
exists.
You cannot show the
zoning library if no
fabric exists. You must
have identified a
switch or director to
the
HAFM
application
for a fabric to exist.
Identify an existing switch or
director to the
HAFM
application using the New
Product dialog box.
Click OK to remove all
contents from log.
This action deletes all
contents from the
selected log.
Click OK to delete the log
contents or Cancel to cancel the
operation.
Connection to
management server
lost.
The connection to the
remote HAFM
appliance has been
lost.
Log in to the HAFM appliance
again through the HAFM Log In
dialog box.
Connection to
management server
lost. Click OK to exit
application.
The
HAFM
application
at a remote
workstation lost the
network connection to
the HAFM appliance.
Re-start the
HAFM
application
to connect to the HAFM
appliance.
Could not export log to
file.
A log file input/output
(I/O) error occurred
and the file could not
be saved to the
specified destination.
The disk may be full or
write protected.
If the disk is full, use another
disk. If the disk is write
protected, change the
write-protect properties or use
another disk.
Default zoning is not
supported in Open
Fabric Mode.
A default zone cannot
be enabled when the
product is enabled for
Open Fabric mode.
Open Fabric mode
does not support zone
members defined by
port numbers.
Change the Interop Mode from
Open Fabric to Homogeneous
using the Configure Fabric
Parameters dialog box. You
can also redefine zone
members by the device WWN.
Device is not a
member of a zone in
the active zone set.
The selected device is
not a member of a
zone in the active zone
set and therefore
cannot communicate
with the other devices
in the route.
Enable the default zone or
activate a zone set containing
the member before attempting
to show the route.
Table 9: HAFM Messages (Continued)
Message Description Action
