FW V06.XX/HAFM SW V08.02.00 HP StorageWorks Director Element Manager User Guide (AA-RTDUC-TE, July 2004)
Table Of Contents
- Contents
- About this Guide
- Overview
- Feature Keys
- Managing the Director
- Element Manager Description
- Using the Element Manager
- Backing Up and Restoring Element Manager Data
- Monitoring and managing the Director
- Hardware View
- Port Card View
- Port List View
- Node List View
- Performance View
- FRU List View
- Port Operational States
- Link Incident Alerts
- Threshold Alerts
- Configuring the Director
- Configuring Identification
- Configuring Management Style
- Configuring Operating Parameters
- Configuring a Preferred Path
- Configuring Switch Binding
- Configuring Ports
- Configuring Port Addresses (FICON Management Style)
- Configuring an SNMP Agent
- Configuring Open Systems Management Server
- Configuring FICON Management Server
- Configuring Feature Key
- Configuring Date and Time
- Configuring Threshold Alerts
- Creating New Alerts
- Figure 49: Configure Threshold Alert(s) dialog box
- Figure 50: New Threshold Alerts dialog box - first screen
- Figure 51: New Threshold Alerts dialog box - second screen
- Figure 52: New Threshold Alerts dialog box - third screen
- Figure 53: New Threshold Alerts dialog box - summary screen
- Figure 54: Configure Threshold Alerts dialog box - alert activated
- Modifying Alerts
- Activating or Deactivating Alerts
- Deleting Alerts
- Creating New Alerts
- Configuring Open Trunking
- Exporting the Configuration Report
- Enabling Embedded Web Server
- Enabling Telnet
- Backing Up and Restoring Configuration Data
- Using Logs
- Using Maintenance Features
- Optional Features
- Information and Error Messages
- Index
Information and Error Messages
223Director Element Manager User Guide
Invalid request. Three conditions result
in this message:
■ You tried to add or
modify a product
from Product View
and the network
address is already
in use. (Network
addresses must be
unique.)
■ You tried to create
a new user with a
username that
already exists. (A
username must be
unique.)
■ You tried to delete
the default
Administrator user.
(The default
Administrator user
cannot be deleted.)
Choose the action that is
appropriate to the activity that
caused the error:
■ Network address: Specify a
unique network address for
the product.
■ username: Specify a unique
username for the new user
ID.
■ Do not delete the default
Administrator user.
Invalid UDP port
number.
The specified user
datagram protocol
(UDP) port number is
invalid. The number
must be an integer
from 1 through 65535
inclusive.
Verify and enter a valid UDP
port number.
Invalid World Wide
Name.
The specified World
Wide Name format is
invalid. The valid
format is eight
two-digit hexadecimal
numbers separated by
colons (xx:xx:xx:xx:
xx:xx:xx:xx).
Enter a World Wide Name
using the correct format.
Table 9: HAFM Messages (Continued)
Message Description Action
