Information and Error Messages
224 Error Messages
Invalid World Wide
Name or nickname.
The World Wide
Name or nickname
that you have specified
is invalid. The valid
format for the World
Wide Name is eight
two-digit hexadecimal
numbers separated by
colons (xx:xx:xx:xx:xx:
xx:xx:xx). The valid
format for a nickname
is non blank
characters, up to 32
characters.
Try the operation again using a
valid World Wide Name or
nickname.
Invalid World Wide
Name. Valid WWN
format is:
xx:xx:xx:xx:xx:
xx:xx:xx.
The specified World
Wide Name format is
invalid. The valid
format is eight
two-digit hexadecimal
numbers separated by
colons (xx:xx:xx:xx:
xx:xx:xx:xx).
Retry the operation using a
valid WWN or nickname.
Invalid zone in zone
set.
The defined zone no
longer exists and is
invalid.
Delete the invalid zone from the
zone set.
Limit exceeded. You cannot add a new
product or user to
HAFM
application if
the maximum number
of that resource
already exists on the
system.
Delete unneeded products or
users from the system, before
attempting to add any new
ones.
No address selected. You cannot complete
the operation because
an address has not
been selected.
Choose an address and retry
the operation.
No attached nodes
selected.
An operation was
attempted without an
attached node
selected.
Choose an attached node and
try the operation again.
Table 9: HAFM Messages (Continued)
Message Description Action
