Information and Error Messages
226 Error Messages
No zone set selected
or zone set no longer
exists.
A zoning operation
was attempted without
a zone set selected, or
the zone set you
selected no longer
exists in the fabric.
Choose a zone set and try the
operation again.
Only attached nodes
can be displayed in
this mode.
You cannot display
unused ports when
adding ports by World
Wide Name.
Change the add criteria to Add
by Port.
Password and
confirmation don’t
match.
Entries in the
password field and
confirmation password
field do not match. The
entries are case
sensitive and must be
the same.
Enter the password and
confirmation password again.
Remote sessions are
not allowed from this
network address.
Only IP addresses of
remote workstations
specified at the Remote
Access dialog box are
allowed to connect to
the HAFM appliance.
Consult with the customer’s
network administrator to
determine if the IP address is to
be configured for remote
sessions.
Remote session
support has been
disabled.
The connection
between the specified
remote workstation
and the HAFM
appliance was
disallowed.
Consult with the customer’s
network administrator to
determine if the workstation
entry should be modified at the
Remote Access dialog box.
Resource is
unavailable.
The specified
operation cannot be
performed because the
product is unavailable.
Verify the HAFM
appliance-to-product link is up.
If the link is up, the HAFM
appliance may be busy. Try the
operation again later.
Route data corrupted. The information for
this route is corrupt.
Try the operation again. If the
problem persists, contact the
next level of support.
Route request timeout. The Show Route
request timed out.
Try the operation again. If the
problem persists, contact the
next level of support.
Table 9: HAFM Messages (Continued)
Message Description Action
