Information and Error Messages
228 Error Messages
The Domain ID was
not accepted. The
World Wide Name
and Domain ID must
be unique in the Fabric
Membership List.
You attempted to add
a detached switch to
the Fabric
Membership List
through the Fabric
Binding option
(SANtegrity Binding
feature), but a switch
already exists in the
fabric with the same
domain ID.
Enter a unique domain ID for
the switch in the Add Detached
Switch dialog box.
The management
server is busy
processing a request
from another Element
Manager.
The HAFM appliance
is processing a request
from another instance
of an Element
Manager and cannot
perform the requested
operation.
Wait until the process
completes, then perform the
operation again.
The link to the
managed product is
not available.
The Ethernet
connection between
the HAFM appliance
and managed product
is down or
unavailable.
Establish and verify the network
connection.
The maximum number
of aliases has already
been configured.
The maximum number
of aliases allowed was
reached.
Delete an existing alias before
adding a new alias.
The maximum number
of management server
network addresses has
already been
configured.
The number of HAFM
appliance IP
addressees that can be
defined to the
HAFM
application has
already been
configured.
Delete an existing IP address
before adding a new address.
The maximum number
of members has
already been
configured.
The maximum number
of unique members is
4097. The maximum
number of members is
8192.
Delete an existing zone
member before adding a new
zone member.
Table 9: HAFM Messages (Continued)
Message Description Action
