Information and Error Messages
229Director Element Manager User Guide
The maximum number
of nicknames has
already been
configured.
The maximum number
of nicknames that can
be defined to the
HAFM
application was
reached.
Delete an existing nickname
before adding a new
nickname.
The maximum number
of open products has
already been reached.
The maximum number
of open switches
allowed was reached.
Close an
Element Manager
session (existing open product)
before opening a new session.
The maximum number
of products has
already been
configured.
The number of
managed HP switches
(48) that can be
defined to the
HAFM
application was
reached.
Delete an existing product
before adding a new product.
The maximum number
of products of this type
has already been
configured.
The number of
managed HP switches
of this type (48) that
can be defined to the
HAFM
application was
reached.
Delete an existing product of
this type before adding a new
product.
The maximum number
of remote network
addresses has already
been configured.
A maximum number
of eight IP addresses
for remote
workstations can be
configured at the
Session Options
dialog box. That
number was reached.
Delete an existing IP address
before adding a new IP
address.
The maximum number
of users has already
been configured.
The number of users
(32) that can be
defined to the
HAFM
application was
reached.
Delete an existing user before
adding a new user.
The maximum number
of zones allowed has
already been
configured.
The maximum number
of zones that can be
defined was reached.
Delete an existing zone before
adding a new zone.
The maximum number
of zone sets has
already been
configured.
The maximum number
of zone sets that can
be defined was
reached.
Delete an existing zone set
before adding a new zone set.
Table 9: HAFM Messages (Continued)
Message Description Action
