Information and Error Messages
230 Error Messages
The maximum number
of zones per zone set
has already been
configured.
The maximum number
of zones that can be
defined in a zone set
was reached.
Delete an existing zone before
adding a new zone to the zone
set.
The nickname does not
exist.
The entered nickname
does not exist in the
fabric.
Configure the nickname to the
appropriate product or select
an existing nickname.
The nickname is
already assigned.
Either use a different
name or do not save
the name as a
nickname.
The entered nickname
already exists in the
fabric. Each nickname
must be unique.
Define a different nickname.
The software version
on this management
server is not
compatible with the
version on the remote
management server.
A second HAFM
appliance (client)
connecting to the
HAFM appliance must
be running the same
software version to log
in.
Upgrade the software version
on the downlevel HAFM
appliance.
The zoning library
conversion must be
completed before
continuing.
The zoning library
conversion is
incomplete and the
requested operation
cannot continue.
Complete the zoning library
conversion, then retry the
operation.
This fabric log is no
longer valid because
the fabric has been
unpersisted.
The selected fabric log
is no longer available
because the fabric has
been unpersisted.
To start a new log for the
fabric, persist the fabric
through the Persist Fabric
dialog box.
This network address
has already been
assigned.
The specified IP
address was assigned
and configured. A
unique address must
be assigned.
Consult with the customer’s
network administrator to
determine a new IP address to
be assigned and configured.
This product is not
managed by this
management server.
The product selected is
not managed by this
HAFM appliance.
Choose a product managed by
this HAFM appliance or go to
the HAFM appliance that
manages the affected product.
Table 9: HAFM Messages (Continued)
Message Description Action
