Information and Error Messages
235Director Element Manager User Guide
Another Element
Manager is currently
performing a firmware
install.
Only one instance of
the Element Manager
can install a firmware
version to the director
at a time.
Wait for the firmware
installation process to complete
and try the operation again.
Are you sure you want
to delete firmware
version?
This message requests
confirmation to delete
a firmware version.
Firmware library can
store up to 8 firmware
versions.
Click Yes to delete the firmware
version or No to abort the
operation.
Are you sure you want
to delete this address
configuration?
Confirmation to delete
the selected address
configuration.
Click Yes to confirm the
deletion of the address
configuration or No to cancel
the operation.
Are you sure you want
to send firmware
version?
This message requests
confirmation to send a
firmware version from
the HAFM appliance’s
firmware library to the
director. Firmware
library can store up to
8 firmware versions.
Click Yes to send the firmware
version or No to abort the
operation.
Cannot change Port
Type while
Management Style is
FICON without
SANtegrity feature.
Please contact your
sales representative.
Firmware is below the
required level and you
attempted to change a
port type in the
Configure Ports dialog
box while FICON
management style, but
the optional
SANtegrity Binding
feature is not installed.
Informational message. If the
firmware is below the required
level, install SANtegrity Binding
before changing port types in
the Configure Ports dialog box
while in FICON management
style.
Cannot disable Switch
Binding while
Enterprise Fabric
Mode is active and the
switch is Online.
You attempted to
disable Switch Binding
through the Switch
Binding Change State
dialog box, but
Enterprise Fabric
Mode is enabled.
You must either disable
Enterprise Fabric Mode using
the Enterprise Fabric Mode
dialog box in the
HAFM
application or set the switch
offline before you can disable
Switch Binding.
Table 10: Element Manager Messages (Continued)
Message Description Action
