FW V06.XX/HAFM SW V08.02.00 HP StorageWorks Director Element Manager User Guide (AA-RTDUC-TE, July 2004)
Table Of Contents
- Contents
- About this Guide
- Overview
- Feature Keys
- Managing the Director
- Element Manager Description
- Using the Element Manager
- Backing Up and Restoring Element Manager Data
- Monitoring and managing the Director
- Hardware View
- Port Card View
- Port List View
- Node List View
- Performance View
- FRU List View
- Port Operational States
- Link Incident Alerts
- Threshold Alerts
- Configuring the Director
- Configuring Identification
- Configuring Management Style
- Configuring Operating Parameters
- Configuring a Preferred Path
- Configuring Switch Binding
- Configuring Ports
- Configuring Port Addresses (FICON Management Style)
- Configuring an SNMP Agent
- Configuring Open Systems Management Server
- Configuring FICON Management Server
- Configuring Feature Key
- Configuring Date and Time
- Configuring Threshold Alerts
- Creating New Alerts
- Figure 49: Configure Threshold Alert(s) dialog box
- Figure 50: New Threshold Alerts dialog box - first screen
- Figure 51: New Threshold Alerts dialog box - second screen
- Figure 52: New Threshold Alerts dialog box - third screen
- Figure 53: New Threshold Alerts dialog box - summary screen
- Figure 54: Configure Threshold Alerts dialog box - alert activated
- Modifying Alerts
- Activating or Deactivating Alerts
- Deleting Alerts
- Creating New Alerts
- Configuring Open Trunking
- Exporting the Configuration Report
- Enabling Embedded Web Server
- Enabling Telnet
- Backing Up and Restoring Configuration Data
- Using Logs
- Using Maintenance Features
- Optional Features
- Information and Error Messages
- Index
Information and Error Messages
238 Error Messages
Cannot retrieve current
SNMP configuration.
The director SNMP
configuration cannot
be retrieved by the
Element Manager
because the Ethernet
link is down or busy.
Retry the operation later. If the
condition persists, contact the
next level of support.
Cannot retrieve
diagnostics results.
Director diagnostic
results cannot be
retrieved by the
Element Manager
because the Ethernet
link is down or busy.
Retry the operation later. If the
condition persists, contact the
next level of support.
Cannot retrieve
information for port.
Port information
cannot be retrieved by
the Element Manager
because the Ethernet
link is down or busy.
Retry the operation later. If the
condition persists, contact the
next level of support.
Cannot retrieve port
configuration.
The port configuration
cannot be retrieved by
the Element Manager
because the Ethernet
link is down or busy.
Retry the operation later. If the
condition persists, contact the
next level of support.
Cannot retrieve port
statistics.
Port statistics cannot
be retrieved by the
Element Manager
because the Ethernet
link is down or busy.
Retry the operation later. If the
condition persists, contact the
next level of support.
Cannot retrieve switch
date and time.
The director or switch
date and time cannot
be retrieved by the
Element Manager
because the Ethernet
link is down or busy.
Retry the operation later. If the
condition persists, contact the
next level of support.
Cannot retrieve switch
state.
The director or switch
state cannot be
retrieved by the
Element Manager
because the Ethernet
link is down or busy.
Retry the operation later. If the
condition persists, contact the
next level of support.
Table 10: Element Manager Messages (Continued)
Message Description Action
