Information and Error Messages
239Director Element Manager User Guide
Cannot run
diagnostics on a port
that is failed.
Port diagnostics
(loopback tests) cannot
be performed on a
port that has failed
any previous
diagnostic (power-on
diagnostic, online
diagnostic, or
loopback test). The
amber LED associated
with the port
illuminates to indicate
the failed state.
Reset the port and perform
diagnostics again.
Cannot run
diagnostics on an
active E-port.
Port diagnostics
cannot be performed
on an active E-port.
Run diagnostics on an E-port
only when it is not active.
Cannot run
diagnostics on a port
that is not installed.
Port diagnostics
cannot be performed
on a port card that is
not installed.
Run diagnostics only on a port
that is installed.
Cannot run
diagnostics on a port
card that is not
installed.
Port diagnostics
(loopback tests) cannot
be performed on a
port that does not have
a small form factor
(SFF) optical
transceiver installed.
Install a transceiver in the port
and perform diagnostics again.
Cannot run
diagnostics while a
device is logged-in to
the port.
Port diagnostics
(internal loopback test)
cannot be performed
on a port while an
attached Fibre
Channel device is
logged in.
Ensure the device is logged out
and perform diagnostics again.
Cannot run
diagnostics while a
device is logged-in to
the port.
A device is logged in
to the port where a
diagnostic test is
attempted.
Log out the device and run the
diagnostic test again.
Cannot save IPL
configuration while
active=saved is
enabled.
You cannot save the
IPL file while the
active=saved property
is set.
The FICON Management
Server property, active=save,
must be disabled for HAFM to
save the IPL file.
Table 10: Element Manager Messages (Continued)
Message Description Action
