Information and Error Messages
240 Error Messages
Cannot save port
configuration.
The port configuration
cannot be saved at the
Element Manager
because the Ethernet
link is down or busy.
Retry the operation later. If the
condition persists, contact the
next level of support.
Cannot save SNMP
configuration.
The SNMP
configuration cannot
be saved at the
Element Manager
because the Ethernet
link is down or busy.
Retry the operation later. If the
condition persists, contact the
next level of support.
Cannot set all ports to
1 Gb/sec due to
speed restriction on
some ports.
Displays if you try to
set ports to operate at
1 Gb/sec data speed
through the Configure
Ports dialog box and
some ports do not
support speed
configuration.
Replace ports that do not
support speed configuration
with those that do support more
than one configuration.
Cannot set all ports to
2 Gb/sec due to
speed restriction on
some ports.
Displays if you try to
set ports to operate at
2 Gb/sec data speed
through the Configure
Ports dialog box and
some ports do not
support speed
configuration.
Replace ports that do not
support speed configuration
with those that do support more
than one configuration.
Cannot set all ports to
Negotiate due to port
speed restriction on
some ports.
Displays if you try to
set all ports to
Negotiate through the
Configure Ports dialog
box and some ports
do not support speed
configuration.
Replace ports that do not
support speed configuration
with those that do support more
than one speed configuration.
Cannot set Fibre
Channel parameters.
Fibre Channel
parameters for the
director cannot be set
at the Element
Manager because the
Ethernet link is down
or busy.
Retry the operation later. If the
condition persists, contact the
next level of support.
Table 10: Element Manager Messages (Continued)
Message Description Action
