Information and Error Messages
241Director Element Manager User Guide
Cannot set switch date
and time.
The switch date and
time cannot be set at
the Element Manager
because the Ethernet
link is down or busy.
Retry the operation later. If the
condition persists, contact the
next level of support.
Cannot set switch
state.
The director or switch
state cannot be set at
the Element Manager
because the Ethernet
link is down or busy.
Retry the operation later. If the
condition persists, contact the
next level of support.
Cannot set write
authorization without
defining a community
name.
A community name
was not defined in the
Configure SNMP
dialog box for the
write authorization
selected.
Provide a name in the Name
field where write authorization
is checked.
Cannot start data
collection.
The data collection
procedure cannot be
started by the Element
Manager because the
Ethernet link is down
or busy.
Retry the operation later. If the
condition persists, contact the
next level of support.
Cannot start firmware
install while CTP
synchronization is in
progress.
The director’s CTP
cards are
synchronizing and
firmware cannot be
installed until
synchronization is
complete.
Install the firmware after CTP
card synchronization
completes.
Cannot start port
diagnostics.
Port diagnostics
cannot be started at
the Element Manager
because the Ethernet
link is down or busy.
Retry the operation later. If the
condition persists, contact the
next level of support.
Cannot swap an
uninstalled port.
A port swap cannot be
performed when the
port card is not
installed.
Perform a swap only on a port
that is installed.
Click OK to remove all
contents from log.
This action deletes all
contents from the
selected log.
Click OK to delete the log
contents or click Cancel to
cancel the operation.
Table 10: Element Manager Messages (Continued)
Message Description Action
