Information and Error Messages
242 Error Messages
Connection to
management server
lost. Click OK to exit
application.
The
HAFM
application
at a remote
workstation lost the
network connection to
the HAFM appliance.
Start the
HAFM
application to
connect to the HAFM
appliance.
Continuing may
overwrite host
programming.
Continue?
Configurations sent
from the host may be
overwritten by HAFM.
Continuing will activate the
current configuration, which
may have been configured by
a FICON host.
Could not export log to
file.
A log file I/O error
occurred and the file
could not be saved to
the specified
destination. The disk
may be full or write
protected.
Ensure file name and drive are
correct.
Could not find
firmware file.
Firmware file selected
was not found in the
FTP directory. Or, the
selected file is not a
firmware file.
Ensure file name and directory
are correct. Or, obtain a valid
firmware file from your service
representative.
Could not remove
dump files from server.
Dump files could not
be deleted from the
HAFM appliance
because the link may
be down, or the HAFM
appliance or Element
Manager is busy.
Retry the operation later. If the
condition persists, contact the
next level of support.
Could not stop port
diagnostics.
Port diagnostics could
not be stopped by the
Element Manager
because the Ethernet
link is down or busy,
or because the director
is busy.
Retry the operation later. If the
condition persists, contact the
next level of support.
Could not write
firmware to flash.
A firmware version
could not be written
from the HAFM
appliance to FLASH
memory
Retry the operation again. If the
condition persists, contact the
next level of support.
Table 10: Element Manager Messages (Continued)
Message Description Action
