Information and Error Messages
243Director Element Manager User Guide
Control Unit Port (CUP)
name and port name
are identical (FICON
ONLY).
Within the address
configuration, one or
more of the port
names are the same as
the CUP name.
Make sure all names are
unique for the ports and CUP
name.
Date entered is invalid. The date is entered
incorrectly at the
Configure Date and
Time dialog box.
Individual field entries
may be correct, but the
overall date is invalid
(for example, a day
entry of 31 for a
30-day month).
Verify each entry is valid and
consistent.
Device applications
should be terminated
before starting
diagnostics. Press
NEXT to continue.
Port diagnostics
(loopback tests) cannot
be performed on a
port while an attached
device application is
running.
Terminate the device
application and perform
diagnostics again.
[device WWN] cannot
be removed from the
Switch Membership
List while participating
in Switch Binding. The
device must be
isolated from the
switch, or Switch
Binding deactivated
before it can be
removed.
You attempted to
remove a device
WWN from the Switch
Membership List
(SANtegrity Binding
feature) while Switch
Binding is enabled.
Remove the device from the
switch by blocking the port,
setting the switch offline, or
disabling Switch Binding
through the Switch Binding
Change State dialog box
before removing devices from
the Switch Membership List.
Director clock alert
mode must be cleared
before enabling
period
synchronization.
Clock alert mode is
enabled through the
Configure FICON
Management Server
dialog box and you
attempted to enable
Periodic Date/Time
Synchronization
through the Configure
Date and Time dialog
box.
Disable clock alert mode
through the Configure FICON
Management Server dialog
box.
Table 10: Element Manager Messages (Continued)
Message Description Action
