Information and Error Messages
247Director Element Manager User Guide
Firmware file I/O
error.
A firmware download
operation aborted
because a file I/O
error occurred.
Retry the operation. If the
problem persists, contact the
next level of support.
Firmware file not
found.
The firmware version
is not installed (or was
deleted) from the
firmware library at the
HAFM appliance.
Add the firmware version to the
library and retry the operation.
Incompatible
configuration between
management style and
management server.
If the Firmware is
below the required
level, only FICON
management style is
allowed if the FICON
Management Server
feature is enabled.
You attempted to
enable Open Systems
management style.
Disable FICON Management
Server, enable the Open
Systems Management Server,
or enable the Open Systems
management style.
Incorrect product type. When configuring a
new product through
the New Product
dialog box, an
incorrect product was
specified.
Choose the correct product
type for the product with the
network address.
Installing this feature
key, while online, will
cause an IPL operation
on the switch and a
momentary loss of
LAN connection. This
operation is
non-disruptive to the
Fibre Channel traffic.
Do you wish to
continue installing this
feature key?
If the switch is online,
installing the new
feature key will cause
an internal program
load (IPL). The LAN
connection to the
HAFM appliance will
be lost momentarily,
but Fibre Channel
traffic will not be
affected.
Click Yes to install the feature
key or No to not install.
Internal file transfer
error received from
director.
The director or switch
detected an internal
file transfer error.
Retry the operation. If the
problem persists, contact the
next level of support.
Invalid character in
field.
An invalid character
was entered in the
Data field.
Remove invalid characters from
the entry.
Table 10: Element Manager Messages (Continued)
Message Description Action
