Information and Error Messages
251Director Element Manager User Guide
Invalid value for
threshold (1-99)%.
Value entered for each
port in the Configure
Open Trunking dialog
box must be in the
range from 1 to 99.
This message only
displays if the optional
Open Trunking feature
is installed.
Enter a number from 1 to 99
into the Threshold % column of
the Configure Open Trunking
dialog box.
Invalid value for year. At the Configure Date
and Time dialog box,
the YYYY value (year)
must be a four-digit
value.
Verify and enter a four-digit
value for the year.
Invalid World Wide
Name or nickname.
The World Wide
Name or nickname
that you have specified
is invalid. The valid
format for the World
Wide Name is eight
two-digit hexadecimal
numbers separated by
colons (xx:xx:xx:xx:xx:
xx:xx:xx). The valid
format for a nickname
is non blank
characters, up to 32
characters.
Try the operation again using a
valid World Wide Name or
nickname.
Link dropped. The HAFM
appliance-to-director
Ethernet link was
dropped.
Retry the operation. Link
re-connects are attempted
every 30 seconds. If the
condition persists, contact the
next level of support.
Log is currently in use. Access to the log is
denied because the
log was opened by
another instance of the
Element Manager.
Retry the operation later. If the
condition persists, contact the
next level of support.
Loopback plug(s) must
be installed on ports
being diagnosed.
Press Next to continue.
External loopback
diagnostics require an
optical loopback plug
to be installed.
Ensure that an optical loopback
plug is installed in port optical
transceiver before running
external wrap diagnostic
testing.
Table 10: Element Manager Messages (Continued)
Message Description Action
