FW V06.XX/HAFM SW V08.02.00 HP StorageWorks Director Element Manager User Guide (AA-RTDUC-TE, July 2004)

Information and Error Messages
252 Error Messages
Maximum number of
versions already
installed.
The number of
firmware versions that
can be defined to the
HAFM application’s
firmware library
(eight) was reached.
Delete an existing firmware
version before adding a new
version.
No file was selected. Action requires the
selection of a file.
Select a file.
No firmware version
file was selected.
A file was not selected
in the Firmware
Library dialog box
before an action, such
as modify or send was
performed.
Click on a firmware version in
the dialog box to select it, then
perform the action again.
No firmware versions
to delete.
There are no firmware
versions in the
firmware library to
delete, therefore the
operation cannot be
performed.
Informational message
only—no action is required.
Nonredundant
director must be offline
to install firmware.
For directors, if the
director has only one
CTP card, the director
must be set offline to
install a firmware
version.
For switches, since the
switch has only a
single CTP card, it
must be offline to
initiate a firmware
installation. Note that
the CTP card is an
internal component
and not a FRU.
Set the director or switch offline
and install the firmware.
Not all of the optical
transceivers are
installed for this range
of ports.
Some ports in the
specified range do not
have optical
transceivers installed.
Use a port range that is valid
for the ports installed.
Table 10: Element Manager Messages (Continued)
Message Description Action
