Information and Error Messages
256 Error Messages
The add firmware
process has been
aborted.
You aborted the
process to add a
firmware version to the
HAFM appliance’s
firmware library.
Verify the firmware addition is
to be aborted, then click OK to
continue.
Switch clock alert
mode must be cleared
before enabling
period
synchronization.
Clock alert mode is
enabled through the
Configure FICON
Management Server
dialog box and user is
attempting to enable
Periodic Date/Time
Synchronization
through the Configure
Date and Time dialog
box.
Disable clock alert mode
through the Configure FICON
Management Server dialog
box.
The data collection
process failed.
An error occurred
while performing the
data collection
procedure.
Try the data collection
procedure again. If the
problem persists, contact the
next level of support.
The data collection
process has been
aborted.
You aborted the data
collection procedure.
Verify the data collection
procedure is to be aborted,
then click OK to continue.
The default zone must
be disabled to
configure.
The message displays
when you attempted to
change the
management style to
Open Fabric and the
default zone is
enabled.
Disable the default zone and
repeat the operation.
The Ethernet link
dropped.
The Ethernet
connection between
the HAFM appliance
and the director is
down or unavailable.
Establish and verify the network
connection.
The firmware file is
corrupted.
A firmware version file
is corrupt.
Contact the next level of
support to report the problem.
The firmware version
already exists.
This firmware version
already exists in
HAFM appliance’s
firmware library.
Informational message
only—no action is required.
Table 10: Element Manager Messages (Continued)
Message Description Action
