Information and Error Messages
258 Error Messages
The switch did not
respond in the time
allowed.
While waiting to
perform a requested
action, the director or
switch timed out.
Retry the operation. If the
condition persists, contact the
next level of support.
The switch is busy
saving maintenance
information.
The director or switch
cannot perform the
requested action
because it is busy
saving maintenance
information.
Retry the operation later. If the
condition persists, contact the
next level of support.
The switch must be
offline to change the
Management Style.
The firmware is below
the required level and
you attempted to
change the
management style.
Choose Set Online State from
the Maintenance menu and
click Set Offline. Then change
the management style. Set the
director or switch back online
when finished.
The switch must be
offline to configure.
A configuration
changed was
attempted for a
configuration
requiring offline
changes.
Take the appropriate actions to
set the director or switch offline
before attempting the
configuration change.
This feature is not
installed. Please
contact your sales
representative.
This feature has not
been installed.
Contact your sales
representative.
This feature key does
not include all of the
features currently
installed and cannot
be activated while the
switch is online.
The feature set
currently installed for
this system contains
features that are not
being installed with the
new feature key. To
activate the new
feature key, you must
set the switch offline.
Activating the new
feature set, however,
will remove current
features not in the new
feature set.
Set the switch offline through
the Set Online State dialog
box, then activate the new
feature key using the Configure
Feature Key dialog box.
The new feature key will
display both the new features
and the features that were
installed previously.
Table 10: Element Manager Messages (Continued)
Message Description Action
