Information and Error Messages
259Director Element Manager User Guide
This feature key does
not include all of the
features currently
installed. Do you want
to continue with
feature key activation?
The feature set
currently installed for
this system contains
features that are not
being installed with the
new feature key.
Click Yes to activate the feature
key and remove current
features not in the new feature
set or No to cancel.
Threshold alerts are
not supported on
firmware earlier than
01.03.00.
Threshold alerts are
not supported on
firmware earlier than
01.03.00.
Informational message.
Unable to change
incompatible firmware
release.
You tried to download
a firmware release
that is not compatible
with the current
product configuration.
Refer to the product release
notes or contact the next level
of support to report the
problem.
Unable to save data
collection file to
destination.
The HAFM appliance
could not save the
data collection file to
the specified location
(PC hard drive, CD, or
network).
Retry the operation. If the
condition persists, contact the
next level of support.
You do not have rights
to perform this action.
Configured user rights
do not allow this
operation to be
performed.
Verify user rights with the
customer’s network
administrator and change as
required.
Table 10: Element Manager Messages (Continued)
Message Description Action
