Overview
26 Director Element Manager User Guide
Note: Figure 3 displays the Director 2/64 Hardware View and Figure 4 displays the
Director 2/140 Hardware View. Other views may display, depending on what you
displayed last before closing the Element Manager.
Figure 3: Director 2/64 Element Manager window
1 Menu Bar
2 View tabs
3 View panel
4 Status bar
2
1
3
4
