Overview
47Director Element Manager User Guide
■ Port Technology
■ Block Port
■ Enable Beaconing
■ Diagnostics
■ Channel Wrap (FICON management style only)
■ Swap Ports (FICON management style only)
■ Clear Link Incident Alert(s)
■ Reset Port
■ Port Binding
■ Clear Threshold Alert(s)
These options also display when you click a port row and choose Product > Port.
For details on these menu options, see “Port Menu” on page 85.
For details on navigating and monitoring using the Port List View, see “Port List
View” on page 90.
Node List View
To display the Node List View, click the Node List view tab. A table, as shown in
Figure 9 displays in the View panel. This table provides information about all
node attachments or N_Ports that have logged in to existing F_Ports on the
director. Only N_Ports display in the Node List View after nodes have logged in to
the fabric.
The columns that display in the table include: port number where the node is
attached, the port’s address, WWN of the attached node’s port, unit type, and
BB_Credit used by the attached node.
To display the Node Properties dialog box for a port, double-click the port row.
To display the following menu options for a port, right-click the port row:
■ Node Properties—Displays the Node Properties dialog box.
■ Port Properties—Displays the Port Properties dialog box.
■ Define Nickname—Displays the Define Nickname dialog box, where you
can define a nickname to display for the attached device instead of the
device’s eight-byte WWN.
