61Director Element Manager User Guide
2
Monitoring and managing the
Director
This chapter describes how to use the features available through the Element
Manager to monitor and manage director operation. These features include
status indicators, menu options, and dialog boxes available through the Hardware
View, Port Card View, Port List View, Node List View, Performance View,
FRU List View.
■ Hardware View, page 62
■ Port Card View, page 78
■ Port List View, page 90
■ Node List View, page 94
■ Performance View, page 99
■ FRU List View, page 107
■ Port Operational States, page 109
■ Link Incident Alerts, page 112
■ Threshold Alerts, page 113
