Monitoring and managing the Director
69Director Element Manager User Guide
6 Power supply failure indicator—When a blinking red and yellow diamond
( ) displays on a power supply with the amber Fault indicator illuminated,
the power supply has failed. The backup power supply has taken over to
supply DC voltage to the director.
Note: A green indicator displays and no status symbols display if the power supply is
working, as shown on the left (position 1) in
Figure 12 and Figure 13.
7 Cooling fan module failure indicator—When a blinking red and yellow
diamond ( ) displays on a fan module with the amber LED indicator
illuminated, the module has failed or is rotating insufficiently.
8 SBAR card beaconing indicator—The yellow triangle status symbol ( )
displaying on the SBAR card, with the amber LED illuminated, indicates that
beaconing has been enabled.
9 SBAR failure indicator—The blinking red and yellow diamond ( )
displaying on the SBAR card with the amber LED illuminated indicates a card
failure.
