Monitoring and managing the Director
73Director Element Manager User Guide
■ Clear System Error Light—Click this option to turn off the amber system
error LED, located below the green power LED on the director front bezel.
■ IPL—Click this option to initiate an IPL on the director. When the dialog box
displays confirming the IPL, click Yes.
For more information, see the HP StorageWorks Director 2/64 Service Guide
for the Director 2/64 and the HP StorageWorks Director 2/140 Service Guide
for the Director 2/140.
Note: An IPL is not intended for ordinary or casual use and should only be performed
when directed by your support personnel.
■ Date/Time—Click this option to display the Configure Date and Time dialog
box, as shown in Figure 17.
The dialog box displays with a check mark (the default) in the Periodic
Date/Time Synchronization check box. If this field is checked, the HAFM
appliance periodically sets the director time to automatically synchronize with
the HAFM appliance time. Daylight savings time automatically updates on
the director using this option.
The current date and time display in the Date and Time fields. If the Periodic
Date/Time Synchronization field is checked, the Date and Time fields are
disabled (grayed out).
To enable and disable Periodic Date/Time Synchronization, click the check
box and then click the Activate button.
Note: FICON management style only—An error results if periodic synchronization and
clock alert mode are enabled (see “Configuring the FICON Management Server” on
page 194).
