Monitoring and managing the Director
93Director Element Manager User Guide
Port List View Menu Options
Right-click a row to display a menu with the following port-related action options.
These are the same menu options that display when you right-click a port in the
Port Card View and a port’s bar graph in the Performance View. You can also click
a port or bar graph in the preceding views and then click Product > Port on the
menu bar. See “Port Menu” on page 85 for an explanation of these menu options.
■ Port Properties
■ Node Properties
■ Port Technology
■ Block Port
■ Enable Beaconing
■ Port(s) Diagnostics
■ Channel Wrap (FICON management style only)
■ Swap Ports (FICON management style only)
■ Clear Link Incident Alert(s)
■ Reset Port
■ Port Binding
■ Clear Threshold Alert(s)
Note: For Node Properties, if a node is not logged in, a message displays indicating
that node information is not available.
